Product Specification
- Dimension (mm): (W) 216 × (H) 138 × (D) 43
- Maximum Operating Ambient Temp.: 50°C
- AC Supply Volt. (Transformer): 16.5 V
- DC Supply Volt.: 12–14 V
- Nominal Battery Charge Volt.: 13.8 V
- Low Battery Detection Volt.: 10.1 V
- Typical Battery Capacity: 12 V, 7 AH
- Reverse Battery Protection: Yes
- AUX Fuse: 2A
- Charge Fuse: 2A
- Siren Fuse: 2A
- Strobe Fuse: 1A
- Supply Current (Idle): 120 mA
- Supply Current (Online): 200 mA
- Max. DC Output Current (Intermittent): 2 A
- End of Line Monitored Inputs: Yes
- End of Line Resistor Value: 1K Ohm
- User Code Length: 4 digits
- Code Lockout Time: <10 sec
- Number of Users: 9 users
- Number of Programmable Zones: 16 zones
- Sensitivity for All Zones: 0–255 level
- No-volatile Memory for Options: Yes
- System Dialer Reporting Method: Personal phone and CMS
- Dual Reporting: Yes
- CMS Dialing Report Format: Contact ID
- Report Types: Sent / Open / Close / Duress / Test / Zone Burglary / Auto Test / Fire / Panic / Restore
- Maximum Dialing Attempts: 10
- Fail to Comm. to Trigger Siren Option: Yes
- Ring Detection: Yes
- Number of Rings to Answer Phone: 0 to 255 rings
- Automatic Dial Tone Detection: Yes
- Digital Decoding / Generation: Yes
- Line Isolation Voltage: >1.5W
- DTMF Output Level (Typical): -5 dBm
- Handshake Receive Sens. (Typical): -43 dBm
- Call Progress Tone Sens. (Typical): -43 dBm
- DTMF Decode Sens. (Typical): -35 dBm
- DTMF Decode Minimum Digit Duration: 45 mSec
- Return Loss (Typical @1kHz, 50mA): 20 dB
